PTC20 nPi TEMPERATURE CONTROLLER

Product Name: nPi PTC20 Temperature Controller
Condition: Used and Fully Functional

Description:

This system guarantees low-noise operation, and the special protection features prevent damage to your experiments. The PTC20 incorporates an electronic thermometer with a semiconductor sensor (R2252 as standard, or optional PT100), providing accurate and reliable temperature monitoring. It also features PI (proportional-integral) control, adjustable parameters, and an output power control unit, all ensuring precise and efficient thermal management.

The PTC20 is suitable for use with Peltier elements (for heating and cooling) or resistive heating elements (for heat-only applications), providing flexible temperature control for a variety of experimental setups. The system supports bipolar output (±12V DC) for continuous operation and can be switched to unipolar operation (+12V) for heat-only applications. Protection circuits, short-circuit protection, and output power limiting (max 12V, 3A) further ensure safety and longevity.

CONDITION: Used and the unit has been fully tested and is in good working condition. It shows minor signs of use but performs perfectly. All controls and display elements are fully functional. Please review the posted photos for a detailed view of its condition and performance. If you have any questions or need additional information, please don’t hesitate to ask.

• Dual Channel Temperature Control: Provides two independent control channels for simultaneous temperature management.
• Heating and Cooling Capabilities: Works with both Peltier (heat/cool) and resistive (heat-only) elements, ideal for versatile applications.
• Precision Temperature Regulation: Equipped with a PI controller that allows for fine adjustment of temperature parameters.
• Digital Temperature Displays: Separate digital displays for each channel, providing accurate, real-time temperature readouts.
• Safety Features: Includes over-temperature protection, short-circuit protection, and electronic output power limiting for enhanced safety.
• Flexible Connectivity: Connects sensors and heating/Peltier elements via separate cables or the ALA DIN cable assembly.
• Compact Design: Housed in a standard 19-inch rackmount cabinet, allowing easy integration into laboratory setups.

Specifications:

• Temperature Control Range: Suitable for a wide range of applications, with flexible heating and cooling control.
• Output Power: Max output voltage of 12V, with a current limited to 3A for safety.
• Temperature Sensors: Includes R2252 (standard) or PT100 (optional) sensors for precise temperature measurement.
• Display: Digital temperature display with direct readout of the set temperature for each channel.
• Power Output: Bipolar output (±12V DC) for heat and cool operation, switchable to unipolar operation (+12V) for heat-only applications.
• Current Protection: Short-circuit protection, electronic output power limiting, and a max current of 3A.
• Rackmount Design: Standard 19-inch rackmount cabinet for easy installation in a laboratory environment.
• Power Supply: Built-in power supply with cooling elements for the power devices.

Condition Details:

• Used and Tested: The system has been thoroughly tested and is in full working order.
• Good Working Condition: Fully operational and capable of precise temperature control for a wide range of applications.

Included Items:

• nPi PTC20 Temperature Controller
• Power Cable (compatible with unit specifications)
• Manual is available on our website.
